40Gbps USB4 Cable

40Gbps USB4 Cable

Model: PR-U4A001

Specifications

Standard	USB4 Gen 3x2 compatible thunderbolt 3 4 Cable
Data Transfer	Up to 40Gbps Bi-directional with USB4 Gen3x2 devices
Video Resolution	8K@60Hz,5K@60Hz,4K@60Hz, 2K@144Hz, 2K@120Hz, 2K@60Hz, 1080P@60Hz (for devices whose USB-C ports support DisplayPort Alternate Mode)
Charging Power	240W of Power Delivery for Fast Charging, also support 240W，100W,96W, 90W, 65W, 60W and more
Power Delivery	PD 3.1/PD 3.0 PPS/PD2.0, QC4.0/3.0, and AFC, SCP, FCP, etc.
Compatible Protocol	Thunderbolt 3, Thunderbolt 4, USB4, USB 3.1, USB3.2,USB 3.0, PD3.1 3.0 PPS/PD2.0, QC4.0/3.0, AFC, SCP, and FCP, etc
Conductor	Tin copper/Pure Copper (OFC)

Product Overview

The USB4 Cable is designed to maximize the performance of modern USB-C devices by combining ultra-fast 40Gbps data transfer, 8K video output, and up to 240W Power Delivery in a single cable. Engineered with premium conductors and advanced shielding technology, it ensures stable, high-speed transmission for demanding applications such as gaming, content creation, workstation setups, external SSDs, and docking stations. Available with OEM customization options, this cable is an ideal solution for consumer electronics, commercial installations, and professional computing environments.

Parameter

Bandwidth	Up to 40Gbps data transfer speed,
Resolution Support	Supports up to 8K@60Hz or dual 4K@60Hz displays
Connector	USB C male to USB C male
Length Options	0.5m, 1m, 1.5m,2m,3m
Wire Gauge	30AWG / 28AWG by length
Shielding	Multi-layer shielding structure minimizes EMI/RFI interference for stable data, video, and power transmission.
Jacket	PVC, TPE, braided, or custom
OEM Options	Logo, color, jacket, connector shell, packaging
MOQ	500 pcs per SKU
Lead Time	15-25 days after sample approval

KEY FEATURES

✓ 40Gbps USB4 Gen3×2 speed

✓ 240W EPR power delivery

✓ Thunderbolt 3 compatible

✓ 8K video output support

✓ Braided nylon jacket

APPLICATIONS

• External SSD / NVMe enclosures
• eGPU connections
• Laptop fast charging
• Docking stations

CERTIFICATIONS

CE RoHS FCC

AVAILABLE LENGTHS

0.5m 1m 2m 3m
